Fabrication & Infrastructure
The Challenge
- Access & safety risks from non-compliant platforms, ladders, and guarding
- Downtime caused by poor fitment or rework on site
- Coatings that fail in dust, heat, or corrosive atmosphere
- No drawings/QA docs \u2192 sign-off delays and insurance issues
- Slow lead times for custom parts (transitions, frames, enclosures)
Our Approach
Avux provides an end-to-end service: site measurement, engineering drawings, fabrication, protective coatings, and installation. We build platforms, ladders, handrails, guarding, skids, duct transitions, and equipment enclosures that fit first time – with QA packs, load ratings, and compliance to SANS/ISO.
Platforms & Walkways
Access platforms, stairs, handrails, and grating per SANS – engineered for load and clearances to improve safe access.
Download spec sheet (PDF).
- Load-rated drawings
- Anti-slip grating
- Kickplates/handrails
Machine Guards & Barriers
Fixed and hinged guarding, belt/drive covers, and interlocked panels for safer machine operation and maintenance.
Download spec sheet (PDF).
- Quick-release panels
- Interlocks
- Visibility windows
Frames, Skids & Bases
Equipment frames, motor plinths, pump skids, and MCC bases with lifting points, leveling, and service access built in.
Download spec sheet (PDF).
- Lifting lugs
- Leveling pads
- Vibration isolation
Ducting & Transitions
Custom transitions, reducers, tees, and mounting hardware for ventilation and process ducting systems.
Download spec sheet (PDF).
- Galv/PVC interfaces
- Flanges/gaskets
- Quick-install kits
Equipment Enclosures
Rugged cabinets and shelters for PLCs, VSDs, analyzers, and radios with IP54–IP66 environmental protection.
Download spec sheet (PDF).
- Sealed cable entries
- Cooling/filters
- Document pockets
Pipe Racks & Cable Trays
Supports and trays with expansion joints, drip trays, and earthing designed for plant and field routing.
Download spec sheet (PDF).
- Hot-dip galvanized
- Bracket kits
- Earthing studs
On-Site Install & Rigging
Installation crews with hot-work permits, rigging plans, and method statements to complete safe, compliant installs.
Download spec sheet (PDF).
- Method statements
- Lift plans
- Permit-to-work
QA, Coatings & Docs
WPS/PQR, welder quals, NDT, DFT reports, and coatings specified for corrosive or high-temperature duty.
Download spec sheet (PDF).
- WPS/PQR/NDT
- DFT reports
- SANS/ISO compliance
Technical Options & Specifications
Materials, joining, coatings, and design documentation aligned to SANS/ISO and site standards – with clear install and QA processes.
- Carbon steel, stainless (304/316), and aluminium where applicable.
- Square/angle/flat/plate; checker plate; serrated grating; FRP grating on request.
- Welding to WPS with qualified welders (PQR available).
- NDT options (VT/MT/PT/UT) per criticality; bolt grades and torque specs.
- Hot-dip galvanizing, epoxy/polyurethane systems, powder coat, zinc-rich primers.
- DFT targets and inspection reports; color coding per client standard.
- CAD (2D/3D) general arrangements, details, and load calculations.
- As-built packs: drawings, material certs, QA logs, DFT, handover checklist.
- SANS / ISO / OSHA principles: stair rise/run, tread, handrail heights, toe-boards.
- Safe access/egress zones, maintenance clearances, and lockable guards.
- Method statements, lifting plans, hot-work permits, and risk assessments.
- Laser leveling, chemical anchors, grout beds as needed.
FAQs – Fabrication & Infrastructure
Yes – GA/detail drawings and load calculations are included, with stamped calculations where required by regulation or insurer.
Typically hot-dip galvanizing plus an epoxy/polyurethane topcoat; we specify systems based on environment class and client standards.
Lead times depend on scope – typically 2–6 weeks from approved drawings, with rapid-response kits available on request.
Yes – we manage method statements, hot-work permits, lift plans, and provide qualified installation and rigging crews.
Yes – paint specifications, RAL codes, labeling, and tagging are matched to your plant standards and documentation requirements.
